·Button function: on/off, zero, data preset, change measuring direction, absolute/incremental measurement ·0-6 hours automatic power off time can be set
·Switchable high/low frequency measurement mode, high frequency mode is suitable for high speed moving of spindle and has large power consumption, low power consumption in low frequency mode
·Keep preset data in memory after restart
·CR2032 battery, automatic power off
·Data output
Resolution 0.001mm
| Code | Range | Accuracy | Hysteresis | Maximum measuring force | Remark |
| KEDI-101F* | 12.7mm | 5μm | 2μm | 1.5N | flat back |
| KEDI-251F* | 25.4mm | 5μm | 3μm | 2.2N | flat back |
| KEDI-501F* | 50.8mm | 6μm | 3μm | 2.5N | flat back |
| KEDI-101* | 12.7mm | 5μm | 2μm | 1.5N | lug back |
| KEDI-251* | 25.4mm | 5μm | 3μm | 2.2N | lug back |
| KEDI-501* | 50.8mm | 6μm | 3μm | 2.5N | lug back |
| KEDI-251P* | 25.4mm | 5μm | 3μm | 2.2N | flat back,with lift cap |
| KEDI-501P* | 50.8mm | 6μm | 3μm | 2.5N | flat back,with lift cap |
Resolution 0.001mm
| Code | Range | Accuracy | Hysteresis | Maximum measuring force | Remark |
| KEDI-10F* | 12.7mm | 20μm | 10μm | 1.5N | flat back |
| KEDI-25F* | 25.4mm | 20μm | 10μm | 2.2N | flat back |
| KEDI-50F* | 50.8mm | 30μm | 10μm | 2.5N | flat back |
| KEDI-10* | 12.7mm | 20μm | 10μm | 1.5N | lug back |
| KEDI-25* | 25.4mm | 20μm | 10μm | 2.2N | lug back |
| KEDI-50* | 50.8mm | 30μm | 10μm | 2.5N | lug back |
| KEDI-25P* | 25.4mm | 20μm | 10μm | 2.2N | flat back,with lift cap |
| KEDI-50P* | 50.8mm | 30μm | 10μm | 2.5N | flat back,with lift cap |
·Button function: on/off, zero, data preset, change measuring direction, absolute/incremental measurement ·0-6 hours automatic power off time can be set
·Switchable high/low frequency measurement mode, high frequency mode is suitable for high speed moving of spindle and has large power consumption, low power consumption in low frequency mode
·Keep preset data in memory after restart
·CR2032 battery, automatic power off
·Data output
Resolution 0.001mm
| Code | Range | Accuracy | Hysteresis | Maximum measuring force | Remark |
| KEDI-101F* | 12.7mm | 5μm | 2μm | 1.5N | flat back |
| KEDI-251F* | 25.4mm | 5μm | 3μm | 2.2N | flat back |
| KEDI-501F* | 50.8mm | 6μm | 3μm | 2.5N | flat back |
| KEDI-101* | 12.7mm | 5μm | 2μm | 1.5N | lug back |
| KEDI-251* | 25.4mm | 5μm | 3μm | 2.2N | lug back |
| KEDI-501* | 50.8mm | 6μm | 3μm | 2.5N | lug back |
| KEDI-251P* | 25.4mm | 5μm | 3μm | 2.2N | flat back,with lift cap |
| KEDI-501P* | 50.8mm | 6μm | 3μm | 2.5N | flat back,with lift cap |
Resolution 0.001mm
| Code | Range | Accuracy | Hysteresis | Maximum measuring force | Remark |
| KEDI-10F* | 12.7mm | 20μm | 10μm | 1.5N | flat back |
| KEDI-25F* | 25.4mm | 20μm | 10μm | 2.2N | flat back |
| KEDI-50F* | 50.8mm | 30μm | 10μm | 2.5N | flat back |
| KEDI-10* | 12.7mm | 20μm | 10μm | 1.5N | lug back |
| KEDI-25* | 25.4mm | 20μm | 10μm | 2.2N | lug back |
| KEDI-50* | 50.8mm | 30μm | 10μm | 2.5N | lug back |
| KEDI-25P* | 25.4mm | 20μm | 10μm | 2.2N | flat back,with lift cap |
| KEDI-50P* | 50.8mm | 30μm | 10μm | 2.5N | flat back,with lift cap |
